Picture for category Fire Alarm & Sirens

Fire Alarm & Sirens

3 Items in Grid 4 Items in Grid List

TNA TXC7001 1 Zone Conventional Fire Alarm Control Panel

Specifications:

Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

Main Circuit Current: 2.8A

Backup Battery: 12.8V, 4Ah

Zone Device Capacity: 30 Devices per Zone

Alarm Bell Output Current: 0.5A per Zone

Auxiliary Power Output: 2 Outputs (0.5A each)

Dimensions (L × W × H): 311mm × 60mm × 251mm

Weight: 1.5kg

Installation Holes Horizontal: 270mm, Vertical: 215mm

Ingress Protection: IP30

Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Contact us For Quote

TNA TXC7002 2 Zone Conventional Fire Alarm Control Panel

Specifications:

Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

Main Circuit Current: 2.8A

Backup Battery: 12.8V, 4Ah

Zone Device Capacity: 30 Devices per Zone

Alarm Bell Output Current: 0.5A per Zone

Auxiliary Power Output: 2 Outputs (0.5A each)

Dimensions (L × W × H): 311mm × 60mm × 251mm

Weight: 1.5kg

Installation Holes: Horizontal: 270mm, Vertical: 215mm

Ingress Protection: IP30

Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Contact us For Quote

TNA TXC7004 4 Zone Conventional Fire Alarm Control Panel

Specifications:

Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

Main Circuit Current: 2.8A

Backup Battery: 12.8V, 4Ah

Zone Device Capacity: 30 Devices per Zone

Alarm Bell Output Current: 0.5A per Zone

Auxiliary Power Output: 2 Outputs (0.5A each)

Dimensions (L × W × H):c311mm × 60mm × 251mm

Weight: 1.5kg

Installation Holes: Horizontal: 270mm, Vertical: 215mm

Ingress Protection: IP30

Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Contact us For Quote

TNA TXC7008 8 Zone Conventional Fire Alarm Control Panel

Specifications:

Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

Main Circuit Current: 2.8A

Backup Battery: 12.8V, 4Ah

Zone Device Capacity: 30 Devices per Zone

Alarm Bell Output Current: 0.5A per Zone

Auxiliary Power Output: 2 Outputs (0.5A each)

Dimensions (L × W × H): 311mm × 60mm × 251mm

Weight: 1.5kg

Installation Holes: Horizontal: 270mm, Vertical: 215mm

Ingress Protection: IP30

Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Contact us For Quote

TNA TXC7012 12-Zone Conventional Fire Alarm Control Panel

Specifications:

- Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

- Main Circuit Current: 2.8A

- Backup Battery: 12.8V, 4Ah

- Zone Device Capacity: 30 Devices per Zone

- Alarm Bell Output Current: 0.5A per Zone

- Auxiliary Power Output: 2 Outputs (0.5A each)

- Dimensions (L × W × H): 311mm × 60mm × 251mm

- Weight: 1.5kg

- Installation Holes: Horizontal: 270mm, Vertical: 215mm

- Ingress Protection: IP30

- Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Contact us For Quote

TNA TX7002 Intelligent Addressable Fire Alarm Control Panel

Specification

Compliance: EN 54-2 & 4

Input Voltage: 230VAC +10%-15%,(120VAC, 60Hz, it is not applicable for EN 54 & Not

tested by L

Input Current Consumption: 0.4A

PSU Output To: CIE21.5~28.5VDC

BatteriesMaximum Charge Capacity: 2 x 12V / 28AH

Maximum Charge Current: 1.2A

I maxA: 0.44A

I maxB: 2.04A

Minimum Quiescent Current: 0.20A(Imin)

Maximum Internal Resistance: 1.0Ω

Rechargeable-Lead acid type battery

Material / Color: Flat sheet Metal

Dimension H x W x D: 460 mm x 440 mm x 165 mm

Weight: 9.40 Kg

Humidity: 0 to 95% Relative Humidity, Non condensing

Contact us For Quote
