Picture for category Smoke & Heat detector

Smoke & Heat detector

3 Items in Grid 4 Items in Grid List

TNA TX7120 Intelligent Addressable Multisensor Fire Detector

Specifications:

- Listed LPCB Certification

- Compliance EN 54-29:2015, EN 54-5: 2017 + A1: 2018,EN 54-7:2018

- Input Voltage 24VDC [16V to 28V]

- Current Consumption Standby 0.6mA, Alarm: 4mA

- Protocol/Addressing T&A, Value range from 1 to 254

- Smoke Sensitivity As per stipulated standard

- Heat Category Type A2R

- Indicator Single LED / 360 degree Visual

- Material / Colour ABS / White Glossy finishing

- Dimension / Height Diameter 99.7 mm / 57 mm

- Weight 145g (with Base), 90g (without Base)

- Operating Temperature -10°C to +50°C

- Humidity 0 to 95% Relative Humidity, Non condensing

Contact us For Quote

TNA TX7110 Intelligent Addressable Heat Detector

Specifications:

- Listed: LPCB Certification

- Compliance: EN 54-5:2000 + A1:2002

- Input Voltage: 24VDC [16V to 28V]

- Current Consumption Standby: 0.6mA, Alarm: 4mA

- Protocol/Addressing T&A, Value range from: 1 to 254

- Heat Class Type: A1R

- Indicator: Single LED / 360 degree Visual

- Material / Colour: ABS / White Glossy finishing

- Dimension / Height Diameter: 99.7 mm / 57 mm

- Weight: 127g (with Base), 72g (without Base)

- Operating Temperature: -10°C to +50°C

- Humidity: 0 to 95% Relative Humidity, Non condensing

Contact us For Quote

TNA DET C631 Conventional Optical Smoke Detector

Specifications:

- Normal Rated Voltage: 24VDC

- Operating Voltage: 9.6VDC to 30VDC

- Quiescent Current: ≤65uA

- Alarm Current: 18 to 22 mA (typical 20mA)

- Remote LED Drive Current Output: Max. 20mA

- Maximum Air Velocity: 7.6m/s

- Weight: 102g (160g with Base DB-6)

- Operating Temp. Range: -10℃ to +50℃

- Relative Humidity: 95%RH, Non condensing @ 40℃

- Alarm LED Indication: Red (Continuous)

- Normal LED Indication: Green (Blinking)

- Ingress Protection: IP42

- Material of Body: ABS Plastic (To UL94V-0 Flammability Test Standards)

- Colour of Body: White

- Standards: EN54-7

- Price mentioned per piece

PKR 3000.00

Global Fire AW CSD311 Conventional Photoelectric Smoke Detector

Specifications:

- Model Number: AW-CSD311

- Detection Method: Photoelectric

- Sensor Type: Optical Sensing Chamber

- Power Supply Voltage: 9 – 32 VDC (non-polarized)

- Standby Current: ≤100μA @24VDC

- Alarm Current (LED On): ≤15mA @24VDC (with 1K Ohm resistance)

- Operating Temperature Range: -10°C to 49°C (14°F to 120°F)

- Humidity Range: 10% – 93% RH (non-condensing)

- Smoke Sensitivity: 1.06 ± 0.26% FT

- Height (with base): 48.2 mm / 2.2 in

- Diameter: 103 mm / 4.0 in

- Weight: 155 g / 5.5 oz

- Mounting Type: Ceiling

- Certifications: CE

- Origin: Guangdong, China

- Price mentioned per piece

PKR 1575.00

Global Fire SEC RTD Dual Mode Heat Detector Rate of Rise and Fixed Temp

Specifications :

- Brand: Global Fire

- Type: Thermal Detector

- Detection Method: Rate of Rise & Fixed Temperature

- Diameter: 102 mm

- Weight: 105 g

- Operating Voltage: 8 – 30 V DC

- Operating Temperature: -30°C to 70°C

- LED Indicator: Bi-color (Red/Green)

- Compatibility: Series 100 detector bases

- Installation: Ceiling Mount

- Price mentioned per piece

PKR 1575.00

Context Plus 65A Photo Electric UL Listed Optical Smoke Detector with Flashing LED

Specifications:

- Detector: Context Plus Series 65A Photo-electric

- PartNo: 55000-326IMC.

- Features: Flashing LED

- Supply voltage: 9 to 33V

- Average stand-by current at: 24V 45µA

- Average stand-by current at: 9V 40µA

- Alarm current at: 24V 52mA

- Alarm current at: 9V 17mA

- Alarm indication: Clear LED, Red in alarm

- Ambient temperature: 32 to 100°F

- Max wind continuous: not affected

- Remote output (R-): Current sink to -ve line, limited to 17mA

- Price mentioned per piece

PKR 3500.00

Context Plus Addressable UL Listed Optical Smoke Detector

Specifications:

- Supply Voltage: 17–28 V DC

- Quiescent Current: 340µA (avg), 600µA peak, 1mA surge

- Wiring: Two-wire, polarity insensitive

- Operating Temp: -20°C to +60°C

- Alarm Indicator: Red LED

- Sensitivity: 2.4%/m light grey smoke obscuration

- Humidity: 0–95% RH (non-condensing, no icing)

- IP Rating: IP43

- Dimensions: Ø100 × 42 mm

- Weight: 105g

- Price mentioned per piece

PKR 9975.00

Context Plus Heat Detector 135°F Series 65A Flame Retardant Emergency Alarm With Flashing LED

Specifications:

- Materials: Polycarbonate

- Dimensions: 3.93 in. dia. x 1.65 in. height

- Weight: 2.80 oz

- Attributes: White flame-retardant

- Terminals: Nickel plated stainless steel

- Price mentioned per piece.

PKR 3500.00
