TNA TXC7004 4 Zone Conventional Fire Alarm Control Panel

Be the first to review this product

Specifications:

Input Voltage: AC 220V (Range: 187V ~ 242V), 50Hz

Main Circuit Current: 2.8A

Backup Battery: 12.8V, 4Ah

Zone Device Capacity: 30 Devices per Zone

Alarm Bell Output Current: 0.5A per Zone

Auxiliary Power Output: 2 Outputs (0.5A each)

Dimensions (L × W × H):c311mm × 60mm × 251mm

Weight: 1.5kg

Installation Holes: Horizontal: 270mm, Vertical: 215mm

Ingress Protection: IP30

Operating Temp / Humidity: 0°C ~ +40°C / ≤95% RH (Non-Condensing)

Qty:

+ -

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Overview
Product Datasheet
Payment Info
Return & Replacements
Reviews
Contact Us

Description

The TXC7004 is a conventional fire alarm control panel designed for smaller-to-medium sized installations. It supports a conventional device architecture where individual detectors, manual call points and sounder circuits are wired to zone inputs rather than addressable loops. The panel features up to 4 zones (model TXC7004) in the series and is housed in a compact metal enclosure with battery backup. Each zone is capable of supporting up to 30 conventional devices.

Key Features

Four conventional fire alarm zones with support for up to 30 devices per zone.
Mains supply: AC 220 V (187 V ~ 242 V), 50 Hz.
Built-in backup battery provision (12.8 V, 4 Ah) to sustain operation during mains failure.
Dedicated alarm (bell) output current rating of 0.5A per zone; auxiliary power outputs (2 × 0.5A) for accessory devices.
Enclosure dimensions: 311 mm (W) × 60 mm (D) × 251 mm (H); installation hole spacing (horizontal 270 mm × vertical 215 mm).
Operating ambient: 0 °C to +40 °C; relative humidity up to 95% non-condensing.
IP rating: IP30 (indoor installation) for standard model.

Industrial Uses / Applications

Small offices, retail outlets
Schools and clinics
Warehouses with modest zone coverage
Residential/apartment fire detection support
