Specifications:
- Compliance: EN 54-11:2001 + A1:2005
- Certifications: LPCB / CE-CPR
- Input Voltage: 24VDC (Range: 16V – 28V)
- Current Consumption: Standby: 0.6 mA / Alarm: 1.8 mA
- Protocol / Addressing: T&A, Range: 1 to 254
- Indicator: Front-Facing LED (Steady On when pressed)
- Glass Type: Non-breakable (No hammer required)
- Material / Finish: Fireproof ABS / Red Glossy
- Mounting: Surface Mount, Type A (Indoor Use)
- Dimensions: 99.7 mm × 57 mm
- Weight: 145 g (with base) / 90 g (without base)
- Operating Temperature: –10 °C to +50 °C
- Ingress Protection: IP43
- Humidity Range: 0 – 95% RH (Non-condensing)
