Description:
New Design S1P Safety Shoes
Light Weight Lace-up Safety Shoes is made with Sanvlar Tech Nylon Fabric and PU/PU Dual Density Outsole. It is designed as EN ISO 20345:2011 Quality with S1P category.
| √ Upper, Lining & Bonding Strength Test Result |
Result |
| Upper Tear Strength ≥ |
120.0 Newtons |
| Upper Tensile Properties ≥ |
15.0 N/mm² |
| Lining Tear Strength ≥ |
15.0 N/mm |
| Bonding Strength ≥ |
4.0 N/mm |
| √ Protection with Composite Toecap (200 Joules) |
Result |
| Impact Resistance: Impact Energy: 200 ± 4 Joules, Internal Height Clearence ≥ 14mm Compression Resistance: Compression Force: (15 ± 0.1) KN, Internal Height Clearence ≥ 14mm |
PASS |
√ Penetration Resistance (1100 N)
|
Result |
| Penetration Resistance Force ≥ 1100 N |
PASS |
| √ Protection With Slip Resistant (SRC) |
Result |
|
Test Requirement : SRA (Eurotile 2+Nal S) Forward Heel Slip ≥0.28 & Forward Flat Slip: ≥0.32
SRB (Steel Floor+Glycerine) Forward Heel Slip ≥0.13 & Forward Flat Slip: ≥0.18
|
PASS |
| Standards : EN ISO20344:2011(5.11) , SRC Means both SRA & SRB requirements are fulfilled. |
|
| √ Protection Against Heat Risk 300℃ |
Result
|
| Test Requirement : The Outsole Did Not Melt & Did Not Develop Any Cracks When Bent Aound Mandrel |
PASS |
| Standards : ENISO 20344:2011(8.7). 300℃ HRO=Heat Resistant |
|
| √ Protection Resistant to Fuel Oil |
Result |
| Test Requirement : Change in Volume and Change in Hardness (Outsole) is No More Than +12%(*) |
PASS |
| Standards : ENISO 20344:2011(8.6.1) |
|
| √ Sole Bonding Strength Test |
|
| • EN ISO 20344:2011, 5.2 (Between Upper & Sole) |
| • Average Test Result 5.8±5 (N/mm) |
| SAFETOE Standard Package Instruction (Average 42# for Reference) |
| Shoes Weight : 1.1-1.2 KGS /Pair |
Carton Weight : 12-13 KGS /Carton |
| 1 Pair / Color Box , Dimensions : 32×21×12CM |
10 Pair / Carton , Dimensions : 62×43×33CM |
User Instructions:
1.) RECOMMENDED TO USE : Construction, Logistics, Mechanics, Glasses Installation, Workshop, Farming, Garden, Oil & Gas, Chemical Factory etc.
2.) LIMITATION TO USE: It is very important that footwear selected must be suitable for the right workplaces. The protection against risks or hazards which are not mentioned in this document is not warranted.
3.) FITTING & SIZE: All footwear are marked with standard size on tongue label. Some are with different size comparation, such as EU size, UK size, US size etc. Please wear footwear in a suitable size Footwear which are too loose or too tight may not provide optimum level of protection.
4.) STORAGE: Keep the footwear in its original packaging, under ordinary temperature, non-humidity conditions and in clean, covered and ventilated premises.
5.) CLEANING: Clean footwear regularly by high quality cleaning treatments recommended as suitable for the purpose. Don't use caustic or corrosive cleaning agents.
