Specifications:
- Mains supply: 230V 50/60Hz.
- Mains rated current: 810mA max.
- Internal power supply: 19V-28.5V (27V nominal). Ripple 7V maximum (battery fault).
- Total output current limited to: 1.5A @ 230Vac continuous, 3A peak (ImaxA eq 800mA).
- Quiescent current: 40mA (on mains fail). Zone quiescent 2mA max.
- Max battery size and type: 2 x 12V 7Ah VRLA connected in series.
- No. of detector zone circuits: 3 @ 19-28Vdc (Max. length per circuit is 250m).
- Max. devices per detector zone: 20 detectors (or 32 detectors/manual call points combined).
- No. of conventional sounder circuits: 3 (two x 1st stage; one x 2nd stage). Max. length per circuit is 50m).
- EOL resistor value: 6800Ω 5% Tol. 0/25W (blue, grey, red, gold).
- Max. sounder output current: 3 x 200mA.
- Auxiliary relays: Six: (1) Fire;
(2) Local Fire;
(3) Extract Fan;
(4) 1st Stage;
(5) 2nd Stage;
(6) Fault. Volt free single pole changeover. Max. switch current 1A;
Max. switch voltage 30Vdc. Five additional relays
- Other outputs: Extinguishant release (21-28Vdc, rated at 1A for 5 mins).
Programmable to delay by 0-60 seconds;
to be active for 1-300 seconds and to flood for 60-1800 seconds.
- Auxiliary inputs: Six: (1) Manual Release;
(2) Flow Switch;
(3) Low Pressure;
(4) Mode;
(5) Hold;
(6) Abort. 8K-2KΩ normal;
1.8K-200Ω active;
150-0Ω short circuit.
EOL value: 6K8 +/-5%, 0.25W.
- Indicators: Multiple indicators are provided – refer to the EP203 instructions for details.
- Expansion connections: Yes – for up to 8 x Remote status units (2 wire RS485 + 2 wire power)
and/or up to 8 x Ecomomy status units (2 wire power + 2 wire mode select).
- Product dimensions (mm): 439 W x 276 H x 70 D mm (back box); 467 W x 293 H x 29 D mm (lid).
- Construction & finish: Metal back box; metal chassis' plastic lid.
- IP Rating: IP30.
- Weight: 4.2kg (without batteries).
- Operating conditions/temperature: -5ºC to +40ºC. Max relative humidity: 95%.
